Allen & Heath Xone:92 MK2

Allen & Heath Xone:92 MK2

£1,420.00
£1,450.00 £1,420.00
Sale Sold out
Taxes included. Shipping calculated at checkout.

The Allen & Heath Xone:92 MK2 offers analogue warmth, precise control, and rock-solid reliability. This updated version, from the classic Xone:92 is designed to inspire the next wave of underground pioneers and Big Room headliners.

Refined Iconic Sound

For over 20 years, the Xone:92 has been the gold standard for analog sound in dance music. The latest version keeps that signature sound DJs and audiences love but enhances it with modern, high-performance analogue components. Expect deep, crowd-moving bass, crisp highs, and the warmth only analogue can deliver. Whether in intimate clubs or at large festivals, this mixer brings a physical connection to your audience.

A Club Legend

The Xone:92 MK2 is a six-channel analogue mixer renowned for its warm, powerful sound, unmatched EQ, and legendary filter section. Known for its sound quality, durability, and intuitive design, the Xone:92 mixer remains a top choice for DJs around the world. Whether at Ibiza superclubs, underground Berlin venues, or London warehouse parties, it’s the trusted mixer for shaping unforgettable performances.

  • 4 Phono/Line Channels + 2 Mic/Line Channels
  • 100% analogue circuitry and mix bus summing
  • Dual analogue Filters with silent switching
  • Precision 4-band EQ control
  • Custom mini innoFADER® Pro for smoother mixing
  • Updated storm grey colourway and refocused UV legend
  • New 3-way, global Channel fader curve switch
  • Improved Channel 1-4 Input Level and source-matching
  • Refined Xone:VCF tapers for enhanced control
  • Optimised RIAA preamps
  • Model: XONE:922
  • Type: Analogue
  • Channels: 4 + 2
  • EQ: 4-Band: CH 1 - 4 ¦ MIC/RTN 1 ¦ MIC/RTN 2
  • BOOTH: STEREO/MONO ¦ MUTE ¦ Level
  • Phono Inputs: 4 x RCA: CH 1 - 4
  • Earth Ground Terminals: x 1 + 2 [Dual Ground Terminal adapter]
  • Stereo Line Inputs: 4 x RCA [CH 1 - 4], 2 x 1/4" TRS [RTN 1 / RTN 2] Mono/Stereo
  • Mic Input: 2 x XLR [MIC 1 / MIC 2]
  • MIX 1 Output: 1 x XLR [Balanced]
  • MIX 2 Output: 1 x 1/4" TRS [Unbalanced]
  • BOOTH Output: 1 x 1/4" TRS [Unbalanced]
  • RECORD Output: 1 x RCA [Unbalanced]
  • Stereo Send/Return I/O: 2 x 1/4" TRS: AUX1 ¦ AUX2 [Mono/Stereo], 2 x 1/4" TRS: RTN 1 ¦ RTN 2 [Mono/Stereo]
  • Aux Sends: 2 x CH 1 - 4 ¦ MIC/RTN 1 ¦ MIC/RTN 2 [selectable Pre/Post]
  • Filters: 2 x Stereo analogue Voltage Controlled Filters, HPF / BPF / LPF Response Select ¦ ON/OFF [soft switched], Adjustable FREQ / RES / LFO, Assignable CH 1- 4 [soft switched]
  • Channel 1 - 4 Faders: 60mm linear Voltage Controlled Amplifier
  • Channel 1 - 4 Fader Curve: Switched ¦ 3-way Global
  • Cross Fader: mini innoFADER Pro standard ¦ 45mm linear VCA ¦ User replaceable
  • Cross Fader Curve: Rotary ¦ Progressive transition to Fast-cut
  • MIDI Assignable: Yes: MIDI CC ¦ MIDI Note ON/OFF
  • MIDI Out: 1 x 5-pin DIN
  • Power Supply: Internal switch mode power unit [SMPS] with auto sensing mains input
  • AC Mains: 100 to 240V AC ¦ 50/60Hz, Consumption 30W max, Rear panel mounted ON/OFF switch
  • Mains Adaptor: 3 pin IEC socket with cable clamp. Molded AC plug [supplied]
  • Output Levels; Nom (0VU) / Max: MIX 1 + 4dBu / + 25dBu, MIX 2 + 6dBu / + 21dBu, BOOTH + 8dBu / + 21dBu, RECORD - 10dBu / + 12dBu
  • Internal headroom: Channels + 22dB
  • Frequency response: LINE IN to MST out +1/-0.5dB from 20Hz to 30kHz
  • Distortion: Typically 0.01% @ 1kHz 0dBu (THD+Noise 22Hz to 22kHz)
  • Crosstalk: < -90dB inter-channel @ 1kHz +10dBu
  • Residual Noise (22Hz - 22kHz): MASTER 1 - 85dBu, MASTER 2 - 85dBu, BOOTH - 85dBu
  • Mix Noise (22Hz - 22kHz): Master 1 - 81dBu, Master 2 - 81dBu, Booth - 81dBu, Record RCA - 90dBu
  • Mic Gain: +30dB, EIN = -126dB (@ 40dB gain with 150R source)
  • RIAA Gain: +35dB @ 1kHz (14mV RMS= 0VU @ 1kHz)
  • Channel Meters: 9 LED - 20dBu to + 10dBu
  • Master Meters: 9 LED - 20dBu to + 10dBu
  • Channel EQ MIC/RTN: HI 12kHz +/-15dB, HM 2.7kHz +/-15dB, LM 270Hz +/-15dB, LO 60Hz +/-15dB
  • Channel EQ 1-4: HI 2.4kHz + 6/-∞dB, HM 1.8kHz + 6/-30dB, LM 320Hz + 6/-30dB, LO 220Hz + 6/-∞dB
  • Channel faders 1-4: 60mm VCA control individually replaceable. < -82dB shutoff @1kHz +10dBu
  • Cross-fader: 45mm innoFADER VCA control. Plug in replacement - user replaceable (A&H part#: AI11470 )
  • Filters: Dual, stereo, analogue Voltage Controlled Filters.
  • Panels: Steel
  • PSU: Internal. Switch-mode
  • Mains Input: 3 pin IEC socket Power Lead: country dependant.
  • AC mains: 100V to 240V AC @ 47/63Hz`
  • Consumption: 30W max Fuse rating 100-240V AC T500mA L
  • [0dBu = 0.775 Volts rms / +4dBu = 1.23V rms / 0dBV = 1 Volt rms / -10dBV = 316mV rms]
  • Height: 106mm [4.2 in]
  • Width: 320mm [12.6 in]
  • Depth: 376mm [14.8 in]
  • Weight: 7Kg
